| วัสดุ: | ผงทังสเตนคาร์ไบด์บริสุทธิ์ 100% | รูปร่าง: | เกี่ยวกับรูปทรงกระบอก |
|---|---|---|---|
| พื้นผิว: | มันวาว | สี: | สีดำ |
| ระดับ: | yg8/yg9c/yg11c | ความหนาแน่น: | 14.90 g/cm³ (yg6x) |
| ความแข็ง: | 93.0 HRA (YG6X) | ทีอาร์เอส: | 2700 MPa (YG6X) |
| ความพรุน: | A02/B00/C00 | ขนาดเกรน: | 0.6-0.8 μm (YG6X) |
| องค์ประกอบของห้องสุขา: | 93.5% (YG6X) | องค์ประกอบนี: | 6.0% (YG6X) |
| องค์ประกอบ TAC: | 0.5% (YG6X) | คำสั่งขั้นต่ำ: | 5 ชิ้น |
| แหล่งพลังงาน: | มีไฟฟ้า | ||
| เน้น: | 100% Pure Tungsten Carbide Powder Buttons,Custom Size Tungsten Carbide Buttons,Cylindrical Tungsten Carbide Buttons |
||
Premium YG8, YG9, YG11, and YG13 grade tungsten carbide buttons designed specifically for the oil and gas industry applications.
| Grade | Composition(% in weight) | Physical Properties | Grain size(μm) | ||||||
|---|---|---|---|---|---|---|---|---|---|
| WC | Ni | Ti | TaC | A/B/C | Densityg/cm³(±0.1) | HardnessHRA(±0.5) | TRS Mpa(min) | Porosity | |
| KD115/YG6X | 93.5 | 6.0 | - | 0.5 | 14.90 | 93.0 | 2700 | A02/B00/C00 | 0.6-0.8 |
| KD335/YG10X | 89.0 | 10.5 | - | 0.5 | 14.40 | 91.8 | 3800 | A02/B00/C00 | 0.6-0.8 |
| KG6/YG6 | 94.0 | 6.0 | - | - | 14.90 | 90.5 | 2500 | A02/B00/C00 | 1.2-1.6 |
| KG8/YG8 | 92.0 | 8.0 | - | - | 14.75 | 90.0 | 3200 | A02/B00/C00 | 1.2-1.6 |
| KG9/YG9 | 91.0 | 9.0 | - | - | 14.60 | 89.0 | 3200 | A02/B00/C00 | 1.2-1.6 |
| KG9C/YG9C | 91.0 | 9.0 | - | - | 14.60 | 88.0 | 3200 | A02/B00/C00 | 1.6-2.4 |
| KG10/KG10 | 90.0 | 10.0 | - | - | 14.50 | 88.5 | 3200 | A02/B00/C00 | 1.2-1.6 |
| KG11/YG11 | 89.0 | 11.0 | - | - | 14.35 | 89.0 | 3200 | A02/B00/C00 | 1.2-1.6 |
| KG11C/YG11C | 89.0 | 11.0 | - | - | 14.40 | 87.5 | 3000 | A02/B00/C00 | 1.6-2.4 |
| KG13/YG13 | 87.0 | 13.0 | - | - | 14.20 | 88.7 | 3500 | A02/B00/C00 | 1.2-1.6 |
| KG13C/YG13C | 87.0 | 13.0 | - | - | 14.20 | 87.0 | 3500 | A02/B00/C00 | 1.6-2.4 |
| KG15/YG15 | 85.0 | 15.0 | - | - | 14.10 | 87.5 | 3500 | A02/B00/C00 | 1.2-1.6 |
| KG15C/YG15C | 85.0 | 15.0 | - | - | 14.00 | 86.5 | 3500 | A02/B00/C00 | 1.6-2.4 |
| KD118/YG8X | 91.5 | 8.5 | - | - | 14.50 | 93.6 | 3800 | A02/B00/C00 | 0.4-0.6 |
| KD338/YG12X | 88.0 | 12.0 | - | - | 14.10 | 92.8 | 2200 | A02/B00/C00 | 0.4-0.6 |
| KD25/P25 | 77.4 | 8.5 | 6.5 | 6.0 | 12.60 | 91.8 | 2200 | A02/B00/C00 | 1.0-1.6 |
| KD35/P35 | 69.2 | 10.5 | 5.2 | 13.8 | 12.70 | 91.1 | 2500 | A02/B00/C00 | 1.0-1.6 |
| KD10/M10 | 83.4 | 7.0 | 4.5 | 4.0 | 13.25 | 93.0 | 2000 | A02/B00/C00 | 0.8-1.2 |
| KD20/M20 | 79.0 | 8.0 | 7.4 | 3.8 | 12.33 | 92.1 | 2200 | A02/B00/C00 | 0.8-1.2 |
NOTE: Customization available per customer drawing or actual sample
At Kedel Technology Co., Ltd. in Chengdu, we value every customer interaction. Your satisfaction drives our continuous improvement, and we appreciate your trust in our premium tungsten carbide products.
